Table 15.6 Switch Configuration And Status - IDT 89HPES64H16G2 User Manual

IDT Register Organization
Notes
PES64H16G2 User Manual
Cfg. Register
Size
Offset Mnemonic
0x0000 DWord SWCTL
0x0004 DWord BCVSTS
0x008C DWord USSBRDELAY
0x0100 DWord SWPART0CTL
0x0104 DWord SWPART0STS
0x0120 DWord SWPART1CTL
0x0124 DWord SWPART1STS
0x0140 DWord SWPART2CTL
0x0144 DWord SWPART2STS
0x0160 DWord SWPART3CTL
0x0164 DWord SWPART3STS
0x0180 DWord SWPART4CTL
0x0184 DWord SWPART4STS
0x01A0 DWord SWPART5CTL
0x01A4 DWord SWPART5STS
0x01C0 DWord SWPART6CTL
0x01C4 DWord SWPART6STS
0x01E0 DWord SWPART7CTL
0x01E4 DWord SWPART7STS
0x0200 DWord SWPART8CTL
0x0204 DWord SWPART8STS
0x0220 DWord SWPART9CTL
0x0224 DWord SWPART9STS
0x0240 DWord SWPART10CTL
0x0244 DWord SWPART10STS
0x0260 DWord SWPART11CTL
0x0264 DWord SWPART11STS
0x0280 DWord SWPART12CTL
0x0284 DWord SWPART12STS
0x02A0 DWord SWPART13CTL
0x02A4 DWord SWPART13STS
0x02C0 DWord SWPART14CTL
0x02C4 DWord SWPART14STS
0x02E0 DWord SWPART15CTL
0x02E4 DWord SWPART15STS
Table 15.6 Switch Configuration and Status (Part 1 of 6)
SWCTL - Switch Control (0x0000) on page 17-1
BCVSTS - Boot Configuration Vector Status (0x0004) on page 17-2
USSBRDELAY - Upstream Secondary Bus Reset Delay (0x008C)
on page 17-4
SWPART[15:0]CTL - Switch Partition x Control on page 17-4
SWPART[15:0]STS - Switch Partition x Status on page 17-4
SWPART[15:0]CTL - Switch Partition x Control on page 17-4
SWPART[15:0]STS - Switch Partition x Status on page 17-4
SWPART[15:0]CTL - Switch Partition x Control on page 17-4
SWPART[15:0]STS - Switch Partition x Status on page 17-4
SWPART[15:0]CTL - Switch Partition x Control on page 17-4
SWPART[15:0]STS - Switch Partition x Status on page 17-4
SWPART[15:0]CTL - Switch Partition x Control on page 17-4
SWPART[15:0]STS - Switch Partition x Status on page 17-4
SWPART[15:0]CTL - Switch Partition x Control on page 17-4
SWPART[15:0]STS - Switch Partition x Status on page 17-4
SWPART[15:0]CTL - Switch Partition x Control on page 17-4
SWPART[15:0]STS - Switch Partition x Status on page 17-4
SWPART[15:0]CTL - Switch Partition x Control on page 17-4
SWPART[15:0]STS - Switch Partition x Status on page 17-4
SWPART[15:0]CTL - Switch Partition x Control on page 17-4
SWPART[15:0]STS - Switch Partition x Status on page 17-4
SWPART[15:0]CTL - Switch Partition x Control on page 17-4
SWPART[15:0]STS - Switch Partition x Status on page 17-4
SWPART[15:0]CTL - Switch Partition x Control on page 17-4
SWPART[15:0]STS - Switch Partition x Status on page 17-4
SWPART[15:0]CTL - Switch Partition x Control on page 17-4
SWPART[15:0]STS - Switch Partition x Status on page 17-4
SWPART[15:0]CTL - Switch Partition x Control on page 17-4
SWPART[15:0]STS - Switch Partition x Status on page 17-4
SWPART[15:0]CTL - Switch Partition x Control on page 17-4
SWPART[15:0]STS - Switch Partition x Status on page 17-4
SWPART[15:0]CTL - Switch Partition x Control on page 17-4
SWPART[15:0]STS - Switch Partition x Status on page 17-4
SWPART[15:0]CTL - Switch Partition x Control on page 17-4
SWPART[15:0]STS - Switch Partition x Status on page 17-4
15 - 13
Register Definition
April 5, 2013
