Table 13.10 I/O Expander 11 - Partition Fundamental Reset Inputs - IDT 89HPES64H16G2 User Manual

IDT SMBus Interfaces
Notes
PES64H16G2 User Manual
I/O Expander 10
SMBus I/O
Expander Type
Bit
1
0 (I/O-0.0)
1 (I/O-0.1)
2 (I/O-0.2)
3 (I/O-0.3)
4 (I/O-0.4)
5 (I/O-0.5)
6 (I/O-0.6)
7 (I/O-0.7)
8 (I/O-1.0)
9 (I/O-1.1)
10 (I/O-1.2)
11 (I/O-1.3)
12 (I/O-1.4)
13 (I/O-1.5)
14 (I/O-1.6)
15 (I/O-1.7)
1.
I/O-x.y corresponds to the notation used for PCA9555 port x I/O pin y.
I/O Expander 11
SMBus I/O
Expander Type
Bit
1
0 (I/O-0.0)
1 (I/O-0.1)
2 (I/O-0.2)
3 (I/O-0.3)
4 (I/O-0.4)
5 (I/O-0.5)
6 (I/O-0.6)
7 (I/O-0.7)
8 (I/O-1.0)
9 (I/O-1.1)
10 (I/O-1.2)
Table 13.10 I/O Expander 11 - Partition Fundamental Reset Inputs (Part 1 of 2)
Signal
I P8ILOCKST
I P9ILOCKST
I P10ILOCKST
I P11ILOCKST
I P12ILOCKST
I P13ILOCKST
I P14ILOCKST
I P15ILOCKST
O P8ILOCKP
O P9ILOCKP
O P10ILOCKP
O P11ILOCKP
O P12ILOCKP
O P13ILOCKP
O P14ILOCKP
O P15ILOCKP
Table 13.9 Pin Mapping I/O Expander 10
Signal
I PART0PERSTN
I PART1PERSTN
I PART2PERSTN
I PART3PERSTN
I PART4PERSTN
I PART5PERSTN
I PART6PERSTN
I PART7PERSTN
I PART8PERSTN
I PART9PERSTN
I PART10PERSTN
13 - 12
Description
Port 8 electromechanical interlock state input
Port 9 electromechanical interlock state input
Port 10 electromechanical interlock state input
Port 11 electromechanical interlock state input
Port 12 electromechanical interlock state input
Port 13 electromechanical interlock state input
Port 14 electromechanical interlock state input
Port 15 electromechanical interlock state input
Port 8 electromechanical interlock output
Port 9 electromechanical interlock output
Port 10 electromechanical interlock output
Port 11 electromechanical interlock output
Port 12 electromechanical interlock output
Port 13 electromechanical interlock output
Port 14 electromechanical interlock output
Port 15 electromechanical interlock output
Description
Partition 0 Fundamental Reset Input
Partition 1 Fundamental Reset Input
Partition 2 Fundamental Reset Input
Partition 3 Fundamental Reset Input
Partition 4 Fundamental Reset Input
Partition 5 Fundamental Reset Input
Partition 6 Fundamental Reset Input
Partition 7 Fundamental Reset Input
Partition 8 Fundamental Reset Input
Partition 9 Fundamental Reset Input
Partition 10 Fundamental Reset Input
April 5, 2013
