Table 8.8 SerDes Transmit Drive Swing in Low Swing Mode at Gen2 Speed

When the PHY enters the Polling.Compliance state and low-swing mode is enabled, the following
occurs:
– The transmit drive level is selected by the Transmit Margin (TM) field in the PCIELCTL2 register.
This field has specific transmit margin levels for full-swing and low-swing mode. The values corre-
sponding to low-swing mode are applied.
– De-emphasis is turned off.

Receiver Equalization Controls

The switch contains SerDes receiver equalization controls on a per-lane basis. The receiver equaliza-
tion circuit has two controls which may be programmed via the SerDes Receiver Equalization Lane Control
(S[x]RXEQLCTL) register. These are:
– Receiver Equalization Zero (RXEQZ): Increases the high-frequency gain of the equalizer.
– Receiver Equalization Boost (RXEQB): Reduces the low-frequency gain of the equalizer.
Together, RXEQZ and RXEQB provide wide programmability and fine grain control over the equalizer's
boost. Refer to the definition of the S[x]RXEQLCTL register for further details on programming these
controls.
Drive Level TDVL_LSG2
764 0x0F
737 0x0E
709 0x0D
682 0x0C
649 0x0B
616 0x0A
583
550
506
462
418
374
320
266
212
158
8 - 14
0x09
0x08
0x07
0x06
0x05
0x04
0x03
0x02
0x01
0x00
