Water Management - Animo OptiBean Service Book

OptiBean /OptiBean XL

3.1 Water management

KW3 1
2
Venting
3
1 3
2
Cold
1
3
water
(Optional)
2
3
2 1
Drip tray drainage.
Optional cold
water unit
*
HOT & COLD
Water supply
Main tap
3/8 "
Calcium &
carbon
WF
cartrige
Code Description
WF Water filter
KW1 Inlet valve
PR Pressure reducer 2 bar
FL1 Flow meter
KW2 Pump 10 bar
NRV Non-return valve
H2-3 Pressure boiler
T2 NTC sensor
DV1 Brewer valve 3/2 way (N.C.
2015/09 Rev. 1.2
DV4
1 3
OPV2
2
12 bar
Hot
water
Drainage
Co ee palets
reservoir wast bin
KW1
3/4 "
Inlet valve
DV2 DV6
1 3 2
2 1 3
OPV1
3 bar
Chocolate / Topping
Mixer
MM 2
Hot (& Cold)
Mixer
water outlet
outlet
PR
Pressure reducing
valve 2 bar
Code Description
DV2 Mixer valve 3/2 way (N.C.)
DV4 Hot water valve 3/2 way (N.C.)
DV6 Water expansion valve 3/2 way (N.O.)
KW3 Cold water valve ( H&C optional)
OPV1 Pressure relief valve 3 bar water expansion
OPV2 Pressure relief valve 12 bar
BM1 Espresso group
MM2 Mixer system
DV7 Venting valve 3/2 way (H&C optional)
21
DV1
3
1
NTC sensor
2 T2
Boiler
Co ee
Ø 37mm
Brewer
BM1
Co ee
outlet
NRV
Non return valve
Pump
KW2
M
FL1
Flowmeter
H2-3
EN
Drain boiler &
manometer
De-scaler inlet
for boiler
