OptiBean /OptiBean XL
Service menu continued ...
Main item Sub-item
2.12 Change PIN New PIN code
code
Pin code
2.13 Additional
settings
Waste bin
management
Cycly counter
Reset cycly counter Reset counter?
Service brewer
Reset service
brewer
Pin Code Table
No.
1
2
3
4
5
6
7
2015/09 Rev. 1.2
Item
Repeat PIN code
(8)
* * * * *
Number of
makings
Hysteresis
Time-out reset
Waste bin signal
xxxxx
Reset counter?
Pin code
3 4 2 4 2
3 1 4 3 4
4 1 3 4 3
4 3 2 3 2
2 3 3 4 1
4 2 1 3 1
2 4 2 4 4
Range Set Description
With this menu item the PIN code can be changed. Use only the keys
1 to 4. The complete service menu is secured behind this PIN code.
This PIN code prevents unintentional changes to the machine settings
by untrained personnel.
● The factory PIN code is 2-2-2-2-2
PIN code forgotten?
In the PIN code input display (operator menu item 1.7) a number is
displayed on the right. Enter the associated PIN code (see the list
below) to access the service menu.
After reaching the set number of brewer
movements, the vending is blocked and on the
0-1000 130
display the message is shown; Out of order -
Waste bin full
After reaching the set number of brewer
movements minus the hysteresis,
0-100 20
on the display the message is shown; waste
bin almost full
The time that the waste bin must have been
removed from the machine (to empty it). When
0-50 sec. 15 s
it is replaced, the (internal) waste bin counter
is reset. Any display messages disappear.
Deactivate waste bin sensor in software
ja-nee ja
(bypass).
This cycle counter counts the number of brews
the brewer has made. Tip; this counter can
0-100.000
be reset after major maintenance when, for
example, the brewer is checked.
Reset cycle counter (Brewer)
When the set number of brews (Brewer) is
0-50.000 25.000 reached, the display shows the message
'Service brewer'.
Reset the Service brewer signal after main-
tenance has been carried out on the brewer.
No. Pin code
8 2 3 2 4 1
9 2 4 3 2 3
10 3 1 3 3 2
11 1 3 3 3 2
12 1 2 4 1 3
13 4 3 1 2 1
14 1 1 1 4 2
61
No. Pin code
15 2 1 2 1 1
16 1 2 2 3 3
17 3 4 1 4 4
18 4 1 4 3 3
19 3 1 2 4 1
20 2 2 3 2 4
