12.1.6 Accepting Tokens only (no Euro's)

Carry out sections 12.1.3 and 12.1.4 beforehand.
1. Open the service menu
2. Set to TOKEN using menu 2.2 Button settings /
Button 1-12 / Price.
3. Block the €0.05 - €2.00 coins using the coin
mechanism DIL switches and the table below.
4. The recipe buttons are only activated after a token is
inserted!
Coin € s1
€ 0.05 S1-1
€ 0.10 S1-2
€ 0.20 S1-3
€ 0.50 S1-4
€ 1.00 S1-5
€ 2.00 S1-6
ON = locked / OFF = free

12.1.7 Coin channel cleaning

From time to time, the coin mechanism should be
cleaned with a light, damp cloth (lukewarm water
containing a mild cleaning agent).
No further maintenance is necessary.
ATTENTION
● The cloth must not be so wet that liquid enters the
system or the circuit board could be damaged.
● Do not use any solvents and/or abrasive cleaning
agents that could attack the plastic.
● We advice to use a water free Surface cleaner (e.g.
Surface 95) to remove the coin channel from grease,
and dirt.
1. Turn off the device.
2. Take the coin mechanism out of the side panel.
3. Carefully open the coin holder valve and hold it
open.
4. Clean the coin holder with a cloth and close the
valve again.
5. Turn on the device again.
s2 Coin £ s1
S1-7 £ 0.05 S1-1
S1-8 £ 0.10 S1-2
S2-1 £ 0.20 S1-3
S2-2 £ 0.50 S1-4
S2-3 £ 1.00 S1-5
S2-4 £ 2.00 S1-6
£ 0.05 new S1-4
£ 0.10 new S1-5
s2
-
-
-
S2-1
S1-7
S1-8
-
-
100
OptiBean /OptiBean XL
S1
S2
A
A
