Service menu continued ...
Main item Sub-item
2.3 Recipe settings <Recipe name> 1
(continued....)
<Recipe name>
12
Sub Item Range
Unit 2 DV 2 WT 0,0-30,0 s
DV 2 0-100 ml
Rinse 2 WT 0,0-20,0 s
Rinse 2 0-15 ml
Topping WT 0,0-30,0 s
Topping 0,00-5,00 s
Cacao WT 0,0-30,0 s
Cacao 0,00-5,00 s
Mixer 2 WT 0,0-30,0 s
Mixer 2
Running time 0,0-10,0 s
Speed 1 20-100%
Time speed 1 0-100%
Speed 2 20-100%
DV 4 WT 0.0-30.0 s
DV 4 0-100 ml
DV 5 WT 0.0-30.0 s
DV 5 0-100 ml
Coffee strength 0-10%
Topping strength 0-10%
Cocoa strength 0-10%
Unit sequence
Unit 1-2
Unit 2-1
KW 3 WT
0.0-30.0 s
KW 3
0-100 ml
52
OptiBean /OptiBean XL
Description
Pressure valve delay time 2
pressure valve measurement quantity 2
Pressure valve rinse water delay time 2
Pressure valve rinse water quantity). Is
automatically offset by DV 2
Topping delay time
Topping product dispensing time
Cocoa delay time
Cocoa product dispensing time
Delay time Mixer 2
Mixing time Mixer 1
1st speed Mixer 1
Time 1st speed Mixer 1
2nd speed Mixer 1
Pressure valve 4 delay time
Pressure valve 4 dispensing quantity
(hot water dispensing)
n.a.
n.a.
With the strength range item an ingredient
can be added to the strength control.
Ingredient strength control:
0 = off / >1 = on
Example: [coffee] 5%
-5% -2.5% 0 2.5% 5%
Set the unit sequence here.
For example, Coffee with Milk:
Unit 1-2 first Coffee (unit 1) then milk
(unit 2).
Cappuccino and/or Latte macchiato:
Unit 2-1 first Milk (unit 2) then Espresso
(unit 1).
Cold water valve 3 delay time *
Cold water valve 3 dispensing quantity *
(* Optional cold water dispensing)
2015/09 Rev. 1.2
