Panasonic DP-8032 Service Manual page 181

No. Item
073- Not Used
074
075 Paper Feed Motor
(3rd Paper Tray)
076 Paper Feed Roller
Clutch
(3rd Paper Tray)
077 Lift Motor
(3rd Paper Tray)
078 Intermediate Roller
Clutch
(3rd Paper Tray)
079 Not Used
080 Paper Feed Roller
Clutch
(4th Paper Tray)
081 Lift Motor
(4th Paper Tray)
082 Intermediate Roller
Clutch
(4th Paper Tray)
083- Not Used
084
085 Paper Feed Roller
Clutch
(Sheet Bypass)
086 Not Used
087 ADU Intermediate Roller
Clutch
088- Not Used
099
100 Inner Upper Paper Exit
Solenoid
101 Inner Lower Paper Exit
Solenoid
102 Paper Transport Unit
Motor
(Exit to Outer Tray)
103 Paper Transport Unit
Motor
(Exit to ADU)
104 Paper Guide Solenoid
ON
105 Paper Guide Solenoid
OFF
106- Not Used
109
Ver. 1.2
F4 Mode (Output Check)
Function
When CST3 PCB CN805-4 signal level changes
to 0V from +5V, activate the Motor.
When CST3 PCB CN806-2 signal level changes
to 0V from +24V, clutch operates.
When CST3 PCB CN804-2 signal level changes
to 0V from +24V, motor rotates in the ascending
direction.
When CST3 PCB CN806-4 signal level changes
to 0V from +24V, clutch operates.
When CST2 PCB CN773-2 signal level changes
to 0V from +24V, clutch operates.
When CST2 PCB CN774-2 signal level changes
to 0V from +24V, motor rotates in the ascending
direction.
When CST2 PCB CN773-4 signal level changes
to 0V from +24V, clutch operates.
When SPC PCB CN715-6 signal level changes to
0V from +24V, clutch operates.
When SPC PCB CN711-2 signal level changes to
0V from +24V, the Clutch operates.
When SPC PCB CN719-3 signal level changes to
0V from +24V, the clutch turns OFF.
When SPC PCB CN719-1 signal level changes to
0V from +24V, the clutch turns.
Paper transport unit motor rotates in the forward
direction.
Paper transport unit motor rotates in the reverse
direction.
When EXFD PCB CN792-1 signal level changes
to 0V from +24V, clutch turns ON for Straight
Paper Exit.
When EXFD PCB CN792-3 signal level changes
to 0V from +24V, clutch turns OFF for Inverting
Paper Exit.
181
DP-8032/8025
Remark
(Ref.No.)
(2402)
1 minute
(1105)
(1168)
1 minute
(957)
1 minute
(1105)
(1168)
1 minute
(975)
1 minute
(975)
1 minute
(975)
(1516)
(1516)
(1320)
(1320)
(1127)
(1127)
