Zaxcom Nomad User's Manual
USB to Mix 8 (USB Type A to DB9M)
USB - DB9M
Pin 1 - Pin 1
Pin 2 - Pin 9
Pin 3 - Pin 8
Pin 4 - Pin 6
Case - Pin 5 (Shield)
AES Digital Input / Output Connectors (DB-15)
Nomad uses a mini DB-15 (DE-15) connector for the AES (digital) input and output connectors.
Top row pins: 5, 4, 3, 2, 1
Middle row pins: 10, 9, 8, 7, 6
Bottom row pins: 15, 14, 13, 12, 11
DB -15 Pin
IN / OUT
Number
1
IN
2
IN
3
OUT
4
IN
5
IN
6
OUT
7
OUT
8
GROUND
9
OUT
10
OUT
11
IN
12
IN
13
OUT
14
IN
15
IN
76
Connector Pin Assignments
AES
Connects to
PAIRS
XLR Pin
3 / 4
2 (+)
1 / 2
2 (+)
5 / 6
2 (+)
7 / 8
2 (+)
5 / 6
2 (+)
1 / 2
3 (--)
1 / 2
2 (+)
GROUND
1
3 / 4
3 (--)
3 / 4
2 (+)
3 / 4
3 (--)
1 / 2
3 (--)
5 / 6
3 (--)
7 / 8
3 (--)
5 / 6
3 (--)
