MAIN MENU

PFL Routing

Pre fader listen routing assigns what will be heard to when the PFL key is pushed.

FADER - PFL follows what is assigned in the fader assign matrix including.

ANALOG - PFL corresponds to analog input. So for example analog input 1 will be PFL 1 and analog input
will be PFL 2.

MP3 Support

Turning on MP3 support will allow Nomad to create MP3 files. The files can be 64, 96 or 128Kbps.
To record MP3 files the primary card will need to be format with the MP3 support turned on to create an MP3
folder on the card. MP3 files can be 64, 96 or 128KbpsThis folder will hold up to 24 hours of MP3 audio (at
64kbps). Please note that after the folder has been filled, the MP3 audio will write over the oldest audio.
Please note if MP3 support is turned on and the primary card was not formatted with MP3 support turned on,
Nomad will not know where to write the MP3 files to and "???" error will be displayed where the MP3
indicator is on the meter screen.
After the primary card is formatted with MP3 support turned on leave MP3 support on while recording. When
MP3 support is on, MP3 files will be written to the MP3 folder on the primary card. When recording make sure
the file is marked for MP3.
To "mark" the file make sure that MP3 is toggled on before the file is closed
(stop recording) the primary file. When MP3 is toggled on when "MP3" appears
in the home meter screen while recording. All marked files will be mirrored as
an MP3 later.
If MP3 support is enabled all files will be "marked" by default. To toggle off
MP3 for a particular file press the A-MIX key before or while recording.
Please note that after the file is closed the file can still be marked by going to
the metadata menu and select the file by pressing the STAR key, "MP3" will be
displayed for that file.
When done, to transfer the MP3 file from the primary card to a USB device or mirror compact flash card. Go to
My Nomad > Mirror Settings > File Type and select MP3. Then when mirror mode is turned on Nomad will
start writing the MP3 files to the selected mirror drive. The file transfer is quick - a 30 minute file will transfer
in about 8 seconds.

MP3 Mix

The MP3 mix menu selects which record tracks Nomad will create MP3 of.

FIRST CH - Selects the first record enabled track.

LAST CH - Selects the last record enabled track.

FIRST TWO - Selects the first two record enabled tracks.

LAST TWO -Selects the last two record enabled tracks.
Please note that if "FIRST" or "LAST" is selected that will be the first or last track that is record enabled in the
primary record enable matrix. So for example if primary tracks 1, 4, 6, 8, 10 are being recorded and FIRST TWO
in the MP3 MIX is selected the MP3 will be that of tracks 1 and 4 if LAST TWO is chosen the MP3 will be of tracks
8 and 10.

F1 Key

This menu sets the function on the F1 key on the FP8 fader panel.
The F1 key can be assigned as a shortcut key to the Metadata page, Record Enable matrix, Track Naming page,
Primary CF menu or Mirror CF menu.

Multi-Trim

Multi-trim allows multiple inputs to be controlled a single trim.
37
Mode Menu
