Primary Card Record Routing - Nomad Lite Only

The primary card record routing in Nomad Lite is slightly different from the card routing in Nomad 10 or 12 as that
Nomad Lite does not have a record enable matrix or a card routing matrix.
Just as with Nomad 10 and 12 all inputs and record busses can be routed to any record track. Please note all ISO
tracks are recorded pre-fade only and all output busses are recorded post-fade.
Record Routing
In Nomad Lite record routing menu select and highlight a card track.
After the track is highlighted scroll through and choose the source to be
assign and record on that track.

Mirror Record Enables - Nomad Lite Only

The mirror record matrix sets which of the primary tracks are copied on Nomad Lite mirror compact flash card.
Enabling Mirror Tracks
To select a track to mirror simply enable a cross point in the appropriate
box.
Please note that it is not necessary to remove any cross points from the
mirror matrix because if a primary card track is set to off in the record
routing menu nothing will be recorded on the primary card and
therefore nothing will be written to the mirror card. This way all of the
mirror tracks can be enabled at all times making it unnecessary to
change the tracks being mirrored every time the record routing is
changed
20
Shows Card Tracks 1 and 2 will
record inputs 1 and 2 and tracks
3 and 4 will record Output
buses 1 and 2
