Record Enables - Nomad 10 and 12

The record enable matrix in Nomad 10 and 12 selects which tracks are enabled and recorded on the primary and
mirror compact flash cards.
Please Note if the sample-rate is set to 88.2 kHz or 96 kHz, only eight primary and mirror tracks can be selected and
recorded.
Record Enables
To enable primary or mirror tracks simply enable a cross point in the
appropriate primary or mirror box.
Please note that it is not necessary to remove any cross points from
the mirror matrix because if a primary card track is not enabled
nothing will be recorded on the primary card and therefore nothing
will be written to the mirror card for that track. This way all of the
mirror tracks can be enabled at all times making it unnecessary to
change the tracks being mirrored every time the primary card enables
are changed.
Nomad 10 / 12 Record Enables
