MAIN MENU

ZaxNet TC Out

ZaxNet time code out allows ZaxNet commands to be embedded in the time code stream of Nomad's time code
output. If ZaxNet time code out is turned on Nomad will output its TRX transmitter commands to a TRX900CL,
IFB100/200 or a QIFB instead of using the ZaxNet transmitter that is built-in to Nomad. To accomplish this simply
connect the time code out of the Nomad to the time code in on the TRX900CL, IFB100/200 or QIFB. Then the
remote commands will be sent to the TRX transmitter via an external ZaxNet transmitter.

IFB Test Tone

IFB test tone turns ON/OFF a test tone that is transmitted on the IFB audio channel to Zaxcom ERX receivers.

Burn ZaxNet Software

This menu is where Nomads ZaxNet software is updated from. The ZaxNet software is embedded within the
Nomad software so no additional software will need to be downloaded. If the ZaxNet software needs to be
updated there will be a note in the release notes of the Nomad software.

IFB Debug

This page is used for factory testing of the IFB.
43
ZaxNet Menu
