MBT-5003 L-Band Up/Down Converter System
Front Panel Operation
5.3.1.1

CONFIG: Remote (Remote Control)

Remote Control: Local
Serial Ethernet
Select Local, Serial, or Ethernet using the
CONFIG: Remote Control
If Remote Control: Local is selected, then remote control will be disabled. Remote monitoring is
still possible.
CONFIG: Remote Control
If Remote Control: Serial is selected:
Serial Config: Interface
Address Baudrate
Select Interface, Address, or Baudrate using the
If Serial Config: Interface is selected:
M&C Bus Interface:
RS485-2W RS485-4W
Select RS485-2W (2-wire) or RS-485 (4-wire) using the
If Serial Config: Address is selected:
Remote Address: 0001
The valid range of addresses is from 1 to 9997. Use the ◄ ► arrow keys to select the
character to edit, then the ▲ ▼ arrow keys to edit the value of the digit, then press ENT.
If Serial Config: Baudrate is selected:
Local M&C Bus Baud Rate:
19200 Baud
Edit the baud rate of the remote control bus, connected locally to the M&C computer. The
value is changed using the
baud are available. Press ENT when done.
Note: The asynchronous character format is FIXED at 8 data bits, 1 stop bit, no parity (8-N-1).
CONFIG: Remote Control
If Remote Control: Ethernet is selected:
Ethernet Config: Gateway
Address MAC SNMP
Select Gateway, Address, MAC, or SNMP using the
(◄ ► E)
◄ ► arrow keys, then press ENT.
Local
Serial
◄ ►
(◄ ► ▲ ▼ E)
(▲ ▼ E)
arrow keys. Values of 2400, 4800, 9600,19200, and 38400
▲ ▼
Ethernet
(◄ ► E)
5–7
arrow keys, then press ENT.
◄ ► arrow keys, then press ENT.
◄ ► arrow keys, then press ENT.
Revision 1
MN-MBT5003
