MBT-5003 L-Band Up/Down Converter System
Ethernet Management
3. Login and remote
command execution
via HyperTerminal
configured as Telnet
Client appears as per
the example to the
right:
6.5
Web Server (HTTP) Interface
Refer to the Remote Commands Specifications tables found in Appendix A. REMOTE
CONTROL for detailed descriptions of the configuration parameters featured on the individual
Web pages shown in this chapter.
6.5.1 Web Server Page Introduction
The embedded Web Server application provides the user with an easy to use interface to
configure and monitor all aspects of the MBT-5003. These Web pages have been designed for
optimal performance when using Microsoft's Internet Explorer Version 5.5 or higher (the
examples shown use Internet Explorer Version 6.0).
The user can fully control and monitor base operations of
the MBT-5003 from the Web Server Interface. By rolling
the cursor over the navigation tabs located at the top of
each page (right), the user can select from the available
nested hyperlinks.
6.5.2 Enabling the Web Server Interface
Note: The IP Address can be found by following the pathway
Ethernet
Address.
To enable the Web Server Interface in the MBT-5003 using only a 100BaseTx remote interface
(this assumes the user's PC is configured to run the Microsoft Windows OS):
1. Select Start, then Run,
then type "cmd" to open
the command prompt
window:
See Chapter 5. FRONT PANEL OPERATION for further information.
6–5
Revision 1
MN-MBT5003
CONFIG: Remote Control
