MBT-5003 L-Band Up/Down Converter System
Appendix A
Command
Arguments
Parameter
(Instruction
for Command
Type
Code and
or Response
Qualifier)
Unit Alarm
MSK=
5 bytes
Mask
Number of
N/A
3 bytes
Unread stored
Events
Number of
N/A
3 bytes
Unread stored
Statistics
Part Number
N/A
Various 1-96
bytes
Reboot
RBT=
1 byte
Description of Arguments
(Note that all arguments are ASCII numeric codes
to Query
Command or Query.
Alarm mask conditions. If an alarm is masked, neither an alarm or a
fault is set, and the user will not know of a problem. Form of abcd,
where:
0 = Alarm, 1 = Fault, 2 = Masked
a = Low Forward RF Power
b = External Reference Lock detect
c = Converter A Not Inserted
d = Converter B Not Inserted
Default value: 2200.
There could be a variable delay in the time it takes for the internal
reference to lock to an external reference, due warm-up
characteristics and frequency differences between the references.
Therefore, the default setting is "masked" for the reference lock
detect. This setting may be changed if the customer so desires.
The delay should be less than 1 s after 30 minutes of warm-up
time.
Query only.
Unit returns the Number of stored Events, which remain Unread in
the form of xxx.
Example: NUE=126
Query only.
Unit returns the Number of stored Statistics, which remain Unread
in the form of xxx.
Example: NUS=126
Query only.
Returns the Comtech EF Data part number of the unit. This part
number is the unit's DOTCODE at the time it was manufactured.
The DOTCODE may be up to 96 printable ASCII characters long.
Example: <1/PNM?'cr'
>0001/PNM=MBT5003.350WRSW00'cr''lf'
Command only.
Soft Reboot
1 = Reboot System
between 48 and 57)
A–12
Response to
Query
Command
(Instruction
(Target to
Code and
controller)
qualifier)
MSK=
MSK?
MSK=abcde
MSK?
MSK*
(See Description of
Arguments)
N/A
NUE?
NUE=xxx
N/A
NUS?
NUS=xxx
N/A
PNM?
PNM=x....x
(See Description of
Argumen ts for return string
details)
RBT =
N/A
RBT=x
RBT?
RBT*
(See Description of
Arguments)
Revision 1
MN-MBT5003
Response to query
(Target to controller)
