MBT-5003 L-Band Up/Down Converter System
Front Panel Operation
Use the ◄ ► arrow keys to select from the choices shown, then press ENT. The following table
identifies each menu branch available from the SELECT: (Main) menu, its content section in this
chapter, and the functional description of each branch:
Menu Branch
Config
Monitor
Info
Utility
Test
5.3.1

SELECT: Config (Configuration)

CONFIG: Remote FltRec
ConvA ConvB RefAdj Redun
Use the ◄ ► arrow keys to select from the submenu choices shown, then press ENT. The following
table identifies each submenu available from the SELECT: Config menu branch – typical for
Converter Unit A or Unit B – its content section in this chapter, and functional description of each
submenu:
Submenu
Remote
FltRec
ConvA
ConvB
RefAdj
Redun
Sect Description
5.3.1
(Configuration) Available submenus permit the user to fully configure the MBT-5003.
Available submenus permit the user to monitor the alarm status of the unit, to view
5.3.2
the log of stored events, and to display the Receive Parameters screen.
(Information) Available submenus permit the user to view information on the unit,
5.3.3
without having to go into configuration screens.
Available submenus permit the user to perform miscellaneous functions, such as
5.3.4
setting the Real-time clock, adjusting the display brightness, etc.
5.3.5 Runs diagnostics tests on the front panel LEDs and VFD to verify operation.
Sect Functional Description
(Remote Control) Permits the user to define whether the unit is being controlled
5.3.1.1 locally or remotely, and identifies the unit address, interface type, and rate and
format of the baud parameters.
(Fault Recovery) Permits the user to configure Fault Recovery (AFR) in Auto or
5.3.1.2
Manual mode.
(Converter Unit A or B) Displays the current configuration of the selected converter,
5.3.1.3
including the frequency, attenuation, and slope.
5.3.1.4 (Ref-Osc Adjust) Permits the user to adjust the reference oscillator.
(Redundancy) Permits the user to identify the redundancy state and mode (refer to
5.3.1.5
Appendix B. MBT-5003 REDUNDANCY OPERATION for further information).
