MBT-5003 L-Band Up/Down Converter System
External Connectors
3.2
MBT-5003 External Connectors
Table 3-1 summarizes the external connectors and identifies the chapter sections that provide
more detailed information. The rear panel connectors are typical for both the MBT-5003-XUR
Up Converter and MBT-5003-XDR Down Converter units. Front panel connectors, if not typical,
are identified as unique to either unit, both in the table as well as chapter sections that follow.
Table 3-1. MBT-5003 Front and Rear Panel External Connectors
Ref Des
Name
N/A
REF OUT
N/A
RF OUT
N/A
RF IN
5/10 MHz
J1
EXT REF IN
J2
IF
J3
COM
J4
RELAY
J5
10/100 ETHERNET
N/A
POWER IN
N/A
GND
3.2.1 Front Panel Connectors
3.2.1.1
REF OUT Connector, Type 'BNC' Female
The REF OUT interface is a type 'BNC' female coaxial connector provided on the
MBT-5003-XUR Up Converter and MBT-5003-XDR Down Converter front panels. It is
used to supply a 5 MHz signal from the chassis reference oscillator. The impedance is
matched for 50/75Ω, and provides an output level of 10 ±5 dBm.
3.2.1.2
RF OUT Connector (MBT-5003-XUR only), Type 'N' Female
The RF OUT connector is a type 'N' female coaxial connector provided only on the
MBT-5003-XUR Up Converter front panel. It provides the upconverted RF output
signal for customer use.
Sect
Connector Type
3.2.1.1
BNC (female)
3.2.1.2
Type 'N' (female)
3.2.1.3
Type 'N' (female)
3.2.2.1
BNC (female)
3.2.2.2
Type 'TNC' (female)
3.2.2.3
9-Pin Type 'D' (male)
3.2.2.4
9-Pin Type 'D' (female)
3.2.2.5
RJ-45
AC Plug
3.2.2.6
IEC
3.2.2.7
#10-32 Stud
3–2
MN-MBT5003
Function
(Front panel – typical)
External 5/10 MHz Reference Output
(Front panel – MBT-5003-XUR only)
RF Output
(Front panel – MBT-5003-XDR only)
RF Input
External 5/10 MHz Reference Input
Upconverted L-Band Input Signal
(MBT-5003-XUR only)
Downconverted L-Band Output Signal
(MBT-5003-XDR only)
Serial Remote Control Interface
Form C Unit Alarm
10/100 Ethernet M&C
Converter Power
Grounding
Revision 1
