MBT-5003 L-Band Up/Down Converter System
Front Panel Operation
5.3.3

SELECT: Info

INFO:Remote ConvA ConvB
PSA PSB RefOsc
The Info menu branch displays read-only information on the current configuration of the unit.
Use the ◄ ► arrow keys to select from the submenu choices shown, then press ENT. The following
table identifies each submenu available from the SELECT: Info menu branch – typical for Converter
Unit A or Unit B – its content section in this chapter, and functional description of each submenu:
Submenu Sect
Remote 5.3.3.1
ConvA
5.3.3.2
ConvB
PSA
5.3.3.3
PSB
RefOsc 5.3.3.4
5.3.3.1

INFO: Remote (Remote Control)

This screen displays if the unit is in Local or Remote mode and gives details of the interface type
selected, etc. For example:
Remote M&C: 100BaseTx
IP Addr: 192.168.001.004
Press ENT or CLR to return to the previous menu.
5.3.3.2

INFO: ConvA or ConvB (Converter Unit 'A' or Converter Unit 'B')

Where 'X' is the selected converter – i.e., Converter (Unit) A or Converter (Unit) B – this screen
displays the unit temperature and, when an MBT-5003-XUR Up Converter is optionally
configured with the Power Monitor feature, the RF power. For example:
ConvX: Temp = +34.1 C
RF Power = +10.0 dBm
Press ENT or CLR to return to the previous menu.
5.3.3.3

INFO: PSA or PSB (Power Supply 'A' or Power Supply 'B')

Where 'X' is the selected power supply – i.e., Power Supply (Unit) A or Power Supply (Unit) B –
this screen displays the 12V, 8V, and 5V power supply. For example:
Power Supply X:
12V=12.2 8V=08.3 5V=05.3
Press ENT or CLR to return to the previous menu.
Functional Description
(Remote Control) Displays if the unit is in Local or Remote mode and gives details of the
interface type selected, etc.
Displays the temperature and RF power for Converter Unit A or Converter Unit B.
Displays the 12V, 8V, and 5V power supplies for Power Supply A or Power Supply B.
Displays the raw voltage of the voltage tuning monitor, and the external reference status.
5–13
Revision 1
MN-MBT5003
