LBC-4000 L-Band Up/Down Converter System
Front Panel Operation
To set the converter's slope value: Use the [↑][↓] arrow keys to select, in 0.1 increments, a
value between 0.0 and 1.0.
Press [ENT] when done.
5.2.1.2

CONFIG Remote (Remote Control)

CONFIG Remote: CtrlMode
Address Interface Baud
Use the [←][→] arrow keys to select CtrlMode, Address, Interface, or Baud, and then press
[ENT].
CONFIG Remote
CONFIG Remote:
Control Mode = Local
Use the [↑][↓] arrow keys to select Local or Remote, and then press [ENT].
When Remote Control Mode=Local, remote control is disabled although
remote monitoring is still possible.
CONFIG Remote
CONFIG Remote:
Unit Address = 0003
You must be in Local mode to edit the Unit Address. Use the [←][→] arrow keys to first select a
digit to edit. Next, use the [↑][↓] arrow keys to change its value. The valid range of addresses is
from 0001 to 9999. Press [ENT] when done.
COINFIG Remote
CONFIG Remote:
Interface =RS-232
You must be in Local mode to select the Serial Remote Interface type. Use the [↑][↓] arrow
keys to select the interface as RS‐232 or RS‐485. change its value. Press [ENT] when done.
CONFIG Remote
CONFIG Baud Params:
Rate=9600 Format=8N1
You must be in Local mode to select the Baud Rate. Use the [←][→] arrow keys to navigate to
the Baud setting. Then, use the [↑][↓] arrow keys to set the Baud rate of the remote control bus
CtrlMode
Address
Interface
Baud
5–8
Revision 4
MN/LBC4000.IOM
