MBT-5003 L-Band Up/Down Converter System
Appendix A
A.6.1 MBT-5003 Base Unit Remote Commands and Queries
Command Arguments
Parameter (Instruction for Command
Type Code and or Response
Qualifier)
Auto Fault AFR= 1 byte,
Recovery
Clear All CAE= None
Stored Events
Circuit CID= 24 bytes,
Identification
Set RTC DAY= 6 bytes
(Real-Time-
Clock) Date
Description of Arguments
(Note that all arguments are ASCII numeric codes
to Query
Command or Query.
The BUC/BDC output will automatically be muted in the event of
detected fault. If auto fault recovery is enabled, it will cause the
output return to its pre-fault mute condition if all faults are cleared.
If disabled, the output will remain muted even if all faults are
cleared.
The clearing of the fault condition will not cause a switch over in a
redundant system unless the currently online unit is faulted. In
which case the newly un-faulted unit will be brought online.
Default Value: 1
Example: <1/AFR=1'cr'
>0001/AFR='cr''lf'
Command only.
Instructs the MBT to clear all Stored Events
This command takes no arguments.
Example: <1/CAE='cr'
>0001/CAE='cr''lf'
Command or Query.
Sets or queries the user-defined Circuit ID string, which is a fixed
length of 24 characters.
Default value: ------------------------
Valid characters include:
Space ( ) * + – . / 0 9 and A thru Z
Command or Query.
A command in the form ddmmyy, where; dd = day of the month,
between 01 and 31, mm = month of the year, between 01 and 12
and yy = year, between 00 and 99 (2000 to 2099)
Example: <1/DAY=240403'cr'
>0001/DAY='cr''lf'
(date = April 24, 2003):
between 48 and 57)
A–8
Response to Query
Command (Instruction
(Target to Code and
controller) qualifier)
AFR = AFR? AFR=x
AFR?
AFR* (Same format as command
arguments)
CAE= N/A N/A
CID= CID? CID=x...x
CID?
(See Description of
Arguments)
DAY= DAY? DAY=xxxxxx
DAY?
DAY* (Same format as command
arguments)
Revision 1
MN-MBT5003
Response to query
(Target to controller)
