MBT-5003 L-Band Up/Down Converter System
Appendix A
Command Arguments
Parameter (Instruction for Command
Type Code and or Response
Qualifier)
IP Address IPA= 18 bytes
Gateway IPG= 15 bytes
Address
Initialize ISP= None
Statistics
Pointer
Local/Remote LRS= 1 byte
State
Unit MAC N/A 17 bytes
Address
Description of Arguments
(Note that all arguments are ASCII numeric codes
to Query
Command or Query.
Used to set the IP address and network prefix for the 10/100
BaseT Ethernet management port, in the format
xxx.xxx.xxx.xxx.yy, where:
xxx.xxx.xxx.xxx is the IP address, and
yy is the network prefix (8-30)
Default Value: 192.168.001.004.24
Example: IPA=-192.168.001.004.24
Command or Query.
Used to set the Gateway IP address for the
10/100 Base Tx Ethernet management port, in the format:
xxx.xxx.xxx.xxx, where:
xxx.xxx.xxx.xxx is the IP address
Default Value: 192.168.001.005
Example: IPG=192.168.001.005
Command only.
Resets internal pointer to allow RNS? Queries to start at the
beginning of the stored statistics log.
Example: ISP=
Command or Query.
Set Local or Remote
0 = Local, 1=Serial, 2=Ethernet\
Default value: 0
Example: LRS=1
Note: The customer will always have query access in either mode.
Also, the LRS command is available in all modes as a means of
acquiring control. The intent of this command is to limit changes
from being made on multiple interfaces at the same time.
Query only.
MAC address of the unit, reported in hexadecimal.
Example: MAC=00-06-B0-00-D2-A7
between 48 and 57)
A–11
Response to Query
Command (Instruction
(Target to Code and
controller) qualifier)
IPA= IPA? IPA= xx.xxx.xxx.xxx.yy
IPA?
IPA* (See Description of
IPA# Arguments)
IPG= IPG? IPG = xxx.xxx.xxx.xxx
IPG?
IPG *
ISP= N/A N/A
ISP?
ISP*
LRS= LRS? LRS=x
LRS?
(Same format as command
arguments)
MAC= MAC? MAC=xx-xx-xx-xx-xx-xx
MAC* (See Description of
Arguments)
Revision 1
MN-MBT5003
Response to query
(Target to controller)
