MBT-5003 L-Band Up/Down Converter System
Front Panel Operation
If Ethernet Config: Gateway is selected:
Ethernet IP Gateway:
192.168.001.002 (◄ ► ▲ ▼)
To edit the IP Gateway Address for the Ethernet M&C port for this unit, first use the ◄ ►
arrow keys to select the digit to edit, then the ▲ ▼ arrow keys to edit the value of that digit.
Press ENT when done.
If Ethernet Config: Address is selected:
Ether IP Address/Range:
192.168.001.002/24(◄ ►▲ ▼)
To edit the IP Address and Range for the Ethernet M&C port for this unit, first use the ◄ ►
arrow keys to select the digit to edit, then the ▲ ▼ arrow keys to edit the value of that digit.
Press ENT when done.
If Ethernet Config: MAC is selected:
M&C Port MAC Address:
00-06-B0-00-01-06
This read-only menu shows the unit MAC address. Once the MAC address has been noted,
press ENT or CLR to return to the previous menu.
If Ethernet Config: SNMP is selected:
SNMP:
Community
Select Community or Traps using the ▲ ▼ arrow keys, then press ENT.
If SNMP: Community is selected:

SNMP Community:

Read
Select Read, Write, or Trap using the ▲ ▼ arrow keys, then press ENT.
If Read is selected:
Read Community: (◄ ►▲▼ E)
public
The user may view or edit the SNMP Read Community string. To edit, first use the ◄
►arrows keys to select the character to edit, then the ▲ ▼ arrows keys to edit that
character. Press ENT when done.
If Write is selected:
Write Community: (◄ ►▲▼ E)
private
The user may view or edit the SNMP Write Community string. To edit, first use the ◄
►arrows keys to select the character to edit, then the ▲ ▼ arrows keys to edit that
character. Press ENT when done.
Traps (◄ ► E)
Write Trap (◄ ► E)
5–8
Revision 1
MN-MBT5003
