MBT-5003 L-Band Up/Down Converter System
Ethernet Management
6.3.3 SNMP Traps
The MBT-5003 has the ability to send out SNMP traps when certain events occur in the unit. The
MBT-5003 sends out traps when a fault occurs in the unit. A trap is sent both when a fault occurs
and is cleared.
The MBT-5003 supports both SNMPv1 traps and SNMPv2 notifications. Which style of traps
the MBT-5003 sends can be configured by the user using the MBT-5003SNMPTrapVersion OID.
The following are the MIB2 v1traps / v2 notifications that the MBT-5003 supports:
MIB2 SNMPv1 trap: Authentication Failure
MIB2 SNMPv2 notifications: Authentication Failure
The following tables are the Faults v1 traps / v2 notifications that the MBT-5003 supports.
Faults SNMPv1 traps:
mbt5000BaseUnitFaultV1
mbt5000ConvAFaultV1
mbt5000ConvBFaultV1
Faults SNMPv2 notifications:
mbt5000BaseUnitFaultEvent
mbt5000ConvAFaultEvent
mbt5000ConvBFaultEvent
5
1.3.6.1.6.3.1.1.5.5
6247501
6247502
6247503
1.3.6.1.4.1.6247.50.2.1.1
1.3.6.1.4.1.6247.50.2.1.2
1.3.6.1.4.1.6247.50.2.1.3
6–3
Revision 1
MN-MBT5003
