Input settings
Set input port properties
Query input
Set analog timing properties
Query analog timing
Reset analog timing properties
Set analog color properties
Save analog color properties
Query analog color properties
Reset analog color properties
Set analog input audio parameters
Query analog input audio properties
Set the no sync picture properties
Query the no sync picture properties
Query timings of the incoming signal
Save preset
Delete preset
Delete all presets
Clone preset
List presets
Delete preset from all input ports
Output settings
Set output video properties
Query output video properties
Section 11. Commands – Quick summary
port properties
properties
Section Command
10.8.1
{:DVII#<in>@<S/A>I=<VIDEO>;
<X1>;<X2>;<HDCP>}
0 {:DVII#<in>@<S/A>I=?}
10.8.3 {:ANALOG#<in>@<S/A>I=<PHS>
;<FHS>;<HS>;<VS>;<HP>;<VP>;}
0 {:ANALOG#<in>@<S/A>I=?}
10.8.5 {:ANALOG#<in>@<S/A>I=
RESET}
10.8.6 {:PICTURE#<in>@<S/A>I=
<DF_CHA>;<DF_CHB>;
<DF_CHC>;<G_CHA>;<G_CHB>;
<G_CHC>;<O_CHA>;<O_CHB>;
<O_CHC>;<CONT>;<SAT>;
<BRIGHT>;<HUE>;)
10.8.7 {:PICTURE#<in>@<S/A>I=SAVE}
10.8.8 {:PICTURE#<in>@<S/A>I=?}
10.8.9 {:PICTURE#<in>@<S/A>I=
FACTORY}
10.8.10
{:AUDIN#<in>@<S/A>I=<VOL>;
<BAL>;<GAIN>;<PHS>;<DCF>}
10.8.11 {:AUDIN#<in>@<S/A>I=?}
10.8.12 {:SETBG#<in>@<S/A>I=
<RED>;<GREEN>;<BLUE>;
<nss>}
10.8.13 {:SETBG#<in>@<S/A>I=?}
10.8.14 {GETTIMINGS#<in>@<S/A>=?}
10.8.15 {:AF#<in>@SI=<IPS>}
10.8.16 {:AF#<in>@SI=DEL;<PID>}
10.8.17
{:AF#<in>@SI=DEL;255}
10.8.18 {:AF#<in>@SI=CL;<PID>}
10.8.19 {:AF#<in>@<S/A>I=LIST}
10.8.20
{:AF#<in>@SI=DELALL;<PID>}
Section Command
10.9.1 {:HDMI#<out>@<S/A>O=
<MODE>;<CSPAC>;<CRANG>;
<SUBS>;<HDCP>;}
10.9.2 {:HDMI#<out>@<S/A>O=?}
