7.1.4. Navigation in the service menu

After the entering the 1
Info: The functions and the settings in the service menu can be modified by Lightware Matrix
Controller software or protocol commands, as well. The last saved values mean the last
saving by any way, instead of the last saving by the service menu.
After every pressing of the FUNCTION SELECT BUTTON the next function will be
selected. (The value feedback LED shows the corresponding last saved value.) The first
menu item will be selected after the last one.
After every pressing of the VALUE SELECT BUTTON the next value will be selected. The
first value will be selected after the last one.

7.1.5. Saving in the service menu

In the service menu the device saves every value changing after some seconds (the
saving time) automatically. If the device exits from service menu (because of a hardware
reset) before the SAVING TIME after a value changing the last modification will be lost.

7.1.6. Exit from service menu

During the service menu the device is suspends its normal operation. The signal
transmission and the communication (USB, RS-232 control and RS-232 pass-through)
are out of work in this case. The only way to restore the normal operation is a hardware
reset. It can be performed by pushing and releasing the RESET button on the rear side of
the device or just plug out then plug in the power supply. The saved settings are stored in
an external storage and the device keeps that after reboot.
Section 7. Service menu
st
menu item and the last saved value will be selected.
