10.8.13. Query the no sync picture properties

Description: This command reads the enabling status and the RGB color code of the no
sync picture on the active input port.
Command {:SETBG#<in>@<S/A>I=?}
Response (SETBG#1@SI=
Legend:
Explanation: The no sync picture is enabled and its color is the (255, 255, 0) RGB coded
Info: Querying of the color of no sync picture is available only on the selected active input.

10.8.14. Query timings of the incoming signal

Description: This command reads out the properties of the incoming signal on the
selected input ports.
Command {:GETTIMINGS#<in>@<S/A>=?} → {:GETTIMINGS#1@SI=?}
Response (GETTIMINGS#<in>@<S/A>=
Legend:
Section 10. Programmers reference
Format
<RED>;<GREEN>;<BLUE>;1)CrLf
Please read section 10.8.12
yellow on the DVI-D input port.
Format
<TLW>;
<LW>;
<HFP>;
<HW>;
<HBP>;
<TH>;
<H>;
<VFP>;
<VW>;
<VBP>;
<TMDS>;
<BPP>;)CrLf
<S/A>: Affected ports:
S = single selected input
A = all inputs
<TLW>: Total Line Width
<LW>: Line Width
<HFP>: Hsync Front Porch
<HW>: Hsync Width
<HBP> Hsync Back Porch
<TH> Total Height
<H> Height
<VFP> Vsync Front Porch
<VW> Vsync Width
<VBP> Vsync Back Porch
<TMDS> TMDS clock in kHz
<BPP> Bit/Pixel
→ {:SETBG#1@SI=?}
← (SETBG#1@SI=255;255;0;1)CrLf
on page 90.
Example
← (GETTIMINGS#1@SI=
2200;
1920;
89;
44;
147;
1125;
1080;
4;
5;
36;
148352;
24;)CrLf
