10.5.6. Upload EDID content to the transmitter
Description: EDID hex bytes can be written directly to the user programmable memory
locations.
Sequence:
Step 1. Prepare the device to accept EDID bytes to the specified location <loc> with
Step 2. Device responds that it is ready to accept EDID bytes with (E_L_S)CrLf
Step 3. Send 1 block of EDID (1 block consist of 8 bytes of hex data represented in ASCII
Step 4. The device acknowledges with response (EL#<num>)
Step 5. Repeat steps 3 and 4 to send the remaining 31 blocks of EDID (32 altogether)
Step 6. After the last acknowledge, the device indicates that the EDID status changed by
Command {WL#<loc>}
Response (E_L_S)CrLf
Command {WB#1●<B1>●<B2>●<B3>
Response (EL#<num>)CrLf
Command {WB#2●<B9>●<B10>
Response (EL#<num>) CrLf
Command {WB#32●<B249>●<B250>
Response (EL#<num>) CrLf
Response (E_S_C) CrLf
Legend: <num> represents the sequential number of every 8 byte part of EDID. <num>
is between 1 and 32. <B1>..<B256> are the bytes of EDID.
Explanation: Full EDID uploaded to memory location U3.
10.5.7. Delete EDID from memory
Description: Clear EDID from memory location <loc>.
Command {DE<loc>}
Response (E_SW_OK)CrLf
Page 80 / 107
command {WL#<loc>}
format) with command:
{WB#<num>●<B1>●<B2>●<B3>●<B4>●<B5>●<B6>●<B7>●<B8>}
sending (E_S_C) CrLf
Format
●<B4>●<B5>●<B6>●<B7> ●<B8>}
●<B11>●<B12>●<B13>
●<B14>●<B15>●<B16>}
●<B251>●<B252>●<B253>
●<B254>●<B255>●<B256>}
Format
(DE_OK)CrLf
(E_S_C)CrLf
Example
→ {wl#u3}
← (E_L_S) CrLf
→ {wb#1 00 FF FF FF FF FF FF 00}
← (EL#1)CrLf
→ {wb#2 38 A3 8E 66 01 01 01 01}
← (EL#2)CrLf
→ {wb#32 36 59 42 0A 20 20 00 96}
← (EL#32)CrLf
← (E_S_C)CrLf
Example
→ {deu3}
←
(E_SW_OK)
←
(DE_OK)CrLf
←
(E_S_C)CrLf
