10.3.6. View CPU firmware compile time

Description: Shows the CPU firmware compile time.
Command {CT}
Response (Compiled:<DATE>●<TIME>●
Legend:
Explanation: The firmware was made in 21.09.2012, 14:06:36 and the identification
number of the firmware is 4427.

10.3.7. View installed I/O boards

Description: Shows the hardware name and revision of the installed cards. The number
of responses varies regarding the frame size (number of slots).
Command {IS}
Response (SL#●0●<MB_DESC>)CrLf
Legend:
Explanation:
UMX-OPT-TX150R and its version number is SCH_1.1 PCB_1.1.

10.3.8. Query all port status

Description: Shows the actual status of all input and output ports.
Command {PS}
Response (PS●<INPUT_D>,<OUTPUT_D>)CrLf
Explanation: This command is reserved for compatibility reasons.
Legend: <INPUT_D> contains 4 decimal numbers. Each number must be 0.
<OUTPUT_D> contains 1 decimal number. It must be 0. The input and output state
tables are separated with a comma "," character.
10.4.

System commands

10.4.1. Query current control protocol

Description: Shows the control protocol.
Command {P_?}
Response (CURRENT●PROTOCOL●=●#<x>)Cr
Legend:
Explanation: Protocol 1 is active here.
Info: User can query the protocol only. This command is reserved for compatibility reasons.
Page 72 / 107
Format
Build:<tag>)CrLf
<DATE> Month, Day and Year
<TIME> Hours, minutes and seconds
<tag> Identification number of the firmware
Format
(SL●END)CrLf
Slot 0 represents the motherboard.
<MB_DESC> The motherboard description contains the name and the
version number.
The extender reports
Format
Format
Lf
<x> stands for the active protocol.
Example
→ {ct}
← (Compiled:Sep 21 2012 14:06:36
Build:4427)CrLf
Example
→ {is}
←
(SL# 0 UMX-OPT-TX150R
SCH_1.1 PCB_1.1)CrLf
←
(SL END)CrLf
that it has one
→ {ps}
← (PS 0000,0)CrLf
→ {p_?}
← (CURRENT PROTOCOL = #1)CrLf
Section 10. Programmers reference
motherboard called
Example
Example
