Explanation: One preset was saved to the input port 2.

10.8.20. Delete preset from all input ports

Description: This command deletes the desired from all analog input ports.
Command {:AF#<in>@SI=DELALL;<PID>}
Response (AF DELETED)CrLf
Legend:
Explanation: This command is reserved for compatibility reasons.
10.9.

Output properties

The following commands are setting up the properties of the output ports. If only one or a
few parameters have to be modified, the protocol enables to mask the other parameters,
so they can stay untouched. To mask a parameter use "x" or "X" as its value.
Example:
Info: If the input port is not a selected, active port and this port is affected by an input
command the response will be N/A.

10.9.1. Set output video properties

Description: This command is for configuring output port settings.
Command
Response
Legend for command:
Section 10. Programmers reference
<LCF>: 28.6363M / (256 * fvsync)
<FCL>: Number of lines in a whole picture
<LCVS> Number of lines during v.sync
<SCN> Screen scan type:
0 = progressive
1 = interlaced
<VSPP> V.sync polarity
0 = negative
1 = positive
<HSPP> H.sync polarity
0 = negative
1 = positive
<VPL> Vertical position in lines
<HPP> Horizontal position in pixels
<VSL> Vertical size in lines
<HSP> Horizontal size in pixels
<FHSP> Full horizontal size in pixels
<PHS> Phase (0 .. 31)
Format
<PID> Preset ID number
{:HDMI#1@SO=H;x;x;x;1;} Set output port no. 2 to HDMI 24 bit.
Format
{:HDMI#<out>@<S/A>O=
<MODE>;
<CSPAC>;
<CRANG>;
<SUBS>;
<HDCP>;}
(HDMI#<out>@<S/A>O=
G<CON><MODE><SIG>
<HDCP><HPD>;
O<MODE><CSPAC>
<CRANG>;<SUBS> <HDCP>)
M<HSUP><AUTH><REP>
<YUV4><YUV2>
<AUD><PCM><DC>CrLf
Example
→ {:af#2@si=delall;1}
← (AF DELETED)CrLf
Example
→ {:HDMI#1@SO=H;x;x;x;1;}
← (HDMI#1@SO=G0H100;OHAAA1;)CrLf
