7.2. The service menu in case of UMX-OPT-TX150R

7.2.1. The device specific structure of the service menu

Select with VIDEO button
DVI-A
Function
VIDEO
Output mode
HDCP input mode
for all inputs
HDCP output mode
NoSyncScreen
enable for all inputs
Video priority
Audio priority
Audio fix
Warning! The values (enable / disable) of the HDCP input mode and the NoSyncScreen functions
(in the highlighted rows) can be set for every input port separately during the normal
operation. The service mode set the value FOR ALL THE INPUT PORTS. The value
feedback LED shows enable value if the NoSnycScreen or the HDCP is enabled on ANY
input port.
The audio priority modes use the following abbreviations: E - Embedded, S – S/PDIF,
Info:
A1 – Analog 1, A2 – Aalog 2 audio input port. For the detaiteld explanation of the
Autoselect mode see sections 6.6,

7.2.2. The device specific service menu display

The menu feedback LEDs are the DVI-A, VGA and HDMI VIDEO LEDs and the DVI-D
AUDIO LED is the value feedback LED in case of the UMX-OPT-TX150R.

7.2.3. Enter the service menu of UMX-OPT-TX150R

Step 1. Supply the unit with +5V DC
Step 2. Press and hold the RESET button.
Step 3. While pressing and holding the RESET button press and hold the VIDEO
Step 4. Release the RESET button.
Step 5. Release the VIDEO SELECT button.
Don't need to unplug video or fiber cables to enter the service menu.
Info:
Section 7. Service menu
Menu item
VGA HDMI
VIDEO VIDEO
Auto
Disable
Auto
Disable
First detect
Static select
Embedded
SELECT button.
Number of blinks on DVI-D audio LED
Select with AUDIO button
1 2
DVI HDMI 24
Enable n/a
Always n/a
Enable n/a
DVI-D
n/a
priority
First Priority
detect E - S - A2
Analog 1 Analog 2
6.7 on pages 31, 35.
UMX-OPT-TX150R
User's Manual
3 4 5
n/a n/a
n/a n/a
n/a n/a
n/a n/a
HDMI
n/a
priority
Priority Priority
S - E - A2 E - A2
S/PDIF n/a
6
n/a
n/a
n/a
n/a
n/a
Priority
S - A2
n/a
Page 51 / 107
