11. Commands – Quick summary
Device Status commands
View product type
View serial number
View Firmware version of the CPU
View installed controllers' firmware
View device's temperature
View CPU firmware compile time
View installed I/O boards
Query all port status
System commands
Query current control protocol
Change RS-232 baud rate
Query RS-232 baud rate
Reload factory defaults
Set the RS-232 operation mode
Query the RS-232 operation mode
Clear HDCP key cache
Count HDCP keys
Restart
View error list
Configure remote alerts
Query level of remote alerts
Set the video priority settings
Query the video priority settings
Set the audio priority settings
Query the audio priority settings
EDID router commands
Save EDID to user memory (Learn EDID)
View emulated EDIDs on all inputs
Watch EDID validity table
View EDID header
Download EDID content from the
Upload EDID content to the
Delete EDID from memory
Page 96 / 107
Section Command
10.3.1 {I}
10.3.2 {S}
10.3.3 {F}
10.3.4 {FC}
10.3.5
{ST}
10.3.6 {CT}
10.3.7 {IS}
10.3.8 {PS}
Section Command
10.4.1 {P_?}
10.4.2 {RS232BAUD=<rate>}
10.4.3 {RS232BAUD=?}
{FACTORY=<f1>;<f2>;...;<fx>}
10.4.4
10.4.5 {RS232=<mode>}
10.4.6 {RS232=?}
10.4.7
{:HDCPRESET}
10.4.8 {:HDCPTEST<in>@<num>}
10.4.9 {RST}
10.4.10 {ELIST=?}
10.4.11 {ELEVELSEND#<p>=<0>;<1>;
<2>;<3>;<4>}
10.4.12 {ELEVELSEND#<p>=?}
10.4.13 {VIDEOPRIORITY=<vpmode>}
10.4.14
{VIDEOPRIORITY=?}
10.4.15 {AUDIOPRIORITY=<apmode>}
10.4.16 {AUDIOPRIORITY=?}
Section Command
10.5.1 {<loc1>:<loc2>}
10.5.2
{VEDID}
10.5.3 {WV<type>}
10.5.4 {WH<loc>}
10.5.5
{WE<loc>}
10.5.6 {WL#<loc>}
10.5.7 {DE<loc>}
Section 11. Commands – Quick summary
