7.2.4. Navigation in the service menu of UMX-OPT-TX150R

The VIDEO SELECT button is the function select button and the AUDIO SELECT button
is the value select button in case of the UMX-OPT-TX150R.

7.2.5. Saving in the service menu in case of the UMX-OPT-TX150R

The SAVING TIME is three seconds in case of the UMX-OPT-TX150R.
In the service menu the device saves every value changing after three seconds
automatically. If the device exits from service menu (because of a hardware reset) before
3 seconds after a value changing the last modification will be lost.

7.2.6. Exit from service menu in case of the UMX-OPT-TX150R

During the service menu the device is suspends its normal operation. The signal
transmission and the communication (USB, RS-232 control and RS-232 pass-through)
are out of work in this case. The only way to restore the normal operation is a hardware
reset. It can be performed by pushing and releasing the RESET button on the rear side of
the device or just plugging out then plugging in the power supply. The saved settings are
stored in an external storage and the device keeps that after reboot.
Page 52 / 107 Section 7. Service menu
