10.8.15. Save preset

Description: This command saves the actual analog timing properties for the current
resolution as a preset.
Command {:AF#<in>@SI=<IPS>}
Response (AF SAVED)CrLf
Legend:

10.8.16. Delete preset

Description: This command deletes the desired preset from the analog input port.
Command {:AF#<in>@SI=DEL;<PID>}
Response (AF DELETED)CrLf
Legend:
Explanation: The command deletes the numbered 2 preset.

10.8.17. Delete all presets

Description: This command deletes all the presets from the analog input port.
Command {:AF#<in>@SI=DEL;255}
Response (AF DELETED)CrLf
Explanation: The command deletes all the presets.

10.8.18. Clone preset

Description: This command clones the desired preset to all of the input ports.
Command {:AF#<in>@SI=CL;<PID>}
Response (AF CLONED)CrLf
Legend:
Explanation: This command is reserved for compatibility reasons.

10.8.19. List presets

Description: This command reads and lists all the saved presets from the analog VGA
input port.
Command {:AF#<in>@<S/A>I=LIST}
Response (AF#<in>:<PID>=
Legend:
Page 92 / 107
Format
<IPS> Input port selector:
S = Properties will be saved to the current input port.
A = Properties will be saved to all of the input ports.
(This option is reserved for compatibility reasons.)
Format
<PID> Preset ID number:
Format
Format
<PID> Preset ID number
Format
<BL>;<LCF>;<FCL>;<LCVS>;
<SCN>;<VSPP>;<HSPP>;
<VPL>;<HPP>;<VSL>;<HSP>;
<FHSP>;<PHS>;)CrLf
(AF END)
<S/A>: Affected ports:
S = single selected input
A = all inputs
<PID> Preset ID number
<BL>: (8 x 28.6363M) / fhsync
Example
→ {:af#2@si=s}
← (AF SAVED)CrLf
Example
→ {:af#2@si=DEL;2}
← (AF DELETED)CrLf
Example
→ {:af#2@si=DEL;255}
← (AF DELETED)CrLf
Example
→ {:af#2@si=CL;1}
← (AF CLONED)CrLf
Example
→ {:af#2@si=list}
←
(AF#2:1=
3045;1249;1864;3;
0;1;1;
50;495;1200;1600;
2161;23;)CrLf
←
(AF END)
