10. Programmers reference

Users can connect to the extender through serial and USB port.
Lightware UMX-OPT-TX150R can be controlled with external devices which can
communicate according to the extender protocol.
10.1.

Serial port settings

UMX-OPT-TX150R uses RS-232 communication port. D-SUB connector pin assignments
can be found in section
The device uses standard RS-232 interface with the following default settings:
The serial port baud rate can be changed with rear panel rotary switch (section
page 26) or protocol command - in case of #0 BAUD RATE rotary state (section
on page 73).
10.2.

Protocol description

The protocol description hereinafter stands for Lightware protocol.
The devices accept commands surrounded by curly brackets - { } - and responds with
data surrounded by round brackets - ( ) - only if a command was successfully executed.
All input commands are converted to uppercase, but respond commands can contain
upper and lower case letters as well.
Legend for control commands:
<in>
<out>
<in²>
<out²>
<loc>
<id>
<id²>
<italic>
CrLf
●
→
←
Section 10. Programmers reference
4.5 on page 19.
57600 Baud, 8 data bit, 1 stop bit, no parity
= input number in 1 or 2 digit ASCII format (01,5,07,16 etc.)
= output number in 1 or 2 digit ASCII format
= input number in 2 digit ASCII format (01, 02, 10, 12 etc.)
= output number in 2 digit ASCII format (01, 02, 10, 12 etc.)
= location number in 1, 2 or 3 digit ASCII format
= id number in 1 or 2 digit ASCII format
= id number in 2 digit ASCII format
= italic parameters are optional
= Carriage return, Line feed (0x0D, 0x0A)
= space character (0x20)
= each command issued by the controller
= each response received from the transmitter
UMX-OPT-TX150R
User's Manual
5.4.4 on
10.4.2
Page 69 / 107
