6.8.3. The assigning table
To help understand the EDID memory structure see the matching table below. It shows
all the EDIDs, their short descriptions and their references.
EDID rotary
EDID rotary
EDID rotary
EDID rotary
Page 42 / 107
Number
on DVI-D
#0
Copy from SC MM OUT (Dynamic EDID)
#1
Factory EDID Universal HDMI (default)
#2
Factory EDID (DVI)
#3
Factory EDID (HDMI)
#4
Factory EDID (HDMI)
#5
Factory EDID (DVI)
#6
User EDID (def.: Univ. HDMI EDID)
#7
User EDID (def.: Univ. HDMI EDID)
#8
User EDID (def.: Univ. HDMI EDID)
#9
User EDID (def.: Univ. HDMI EDID)
Number
on DVI-A
#0
Copy from SC MM OUT (Dynamic EDID)
#1
Factory EDID Universal Analog (default)
#2
Factory EDID (Analog) 1024x768@60
#3
Factory EDID (Analog) 1280x720@60
#4
Factory EDID (Analog) 1920x1080@60
#5
Factory EDID (Analog) 1920x1200@60
#6
User EDID (def.: Univ. Analog EDID)
#7
User EDID (def.: Univ. Analog EDID)
#8
User EDID (def.: Univ. Analog EDID)
#9
User EDID (def.: Univ. Analog EDID)
Number
on VGA
#0
Copy from SC MM OUT (Dynamic EDID)
#1
Factory EDID Universal Analog (default)
#2
Factory EDID (Analog) 1024x768@60
#3
Factory EDID (Analog) 1280x720@60
#4
Factory EDID (Analog) 1920x1080@60
#5
Factory EDID (Analog) 1920x1200@60
#6
User EDID (def.: Univ. Analog EDID)
#7
User EDID (def.: Univ. Analog EDID)
#8
User EDID (def.: Univ. Analog EDID)
#9
User EDID (def.: Univ. Analog EDID)
Number
on HDMI
#0
Copy from SC MM OUT (Dynamic EDID)
#1
Factory EDID Universal HDMI (default)
#2
Factory EDID (DVI)
#3
Factory EDID (HDMI)
#4
Factory EDID (HDMI)
#5
Factory EDID (DVI)
#6
User EDID (def.: Univ. HDMI EDID)
#7
User EDID (def.: Univ. HDMI EDID)
#8
User EDID (def.: Univ. HDMI EDID)
#9
User EDID (def.: Univ. HDMI EDID)
EDIDs for DVI-D Input
1024x768@60
1280x720p@60
1920x1080p@60
1920x1200@60
EDIDs for DVI-A Input
EDIDs for VGA Input
EDIDs for HDMI Input
1024x768@60
1280x720p@60
1920x1080p@60
1920x1200@60
Section 6. Operation of UMX-OPT-TX150R
EDID reference
in protocol
D01
F01
F02
F03
F04
F05
U01
U02
U03
U04
EDID reference
in protocol
D01
F06
F07
F08
F09
F10
U05
U06
U07
U08
EDID reference
in protocol
D01
F11
F12
F13
F14
F15
U09
U10
U11
U12
EDID reference
in protocol
D01
F16
F17
F18
F19
F20
U13
U14
U15
U16
