Explanation: There are no errors only standard notices that occur on boot up.
Info: The error list can contain NOTICEs and WARNINGs under normal operation. These
entries do not mean that there is any problem with the matrix!

10.4.11. Configure remote alerts

Description: The device logs different levels of errors. Configure which level of errors
has to be sent out as an alarm message.
Command
Response (ELEVELSEND#<p>=
Explanation: The device will send an immediate message on all control interfaces when
a 'matter', 'error' or 'fatal' level error occurs.
Legend: <p>: Adjusted control interface

10.4.12. Query level of remote alerts

Description: User can check which level of errors has to be sent out as an alarm
message.
Command {ELEVELSEND#<p>=?}
Response (ELEVELSEND#<p>=
Legend:
Explanation: The device will send an immediate message on all control interfaces when
a 'matter', 'error' or 'fatal' level error occurs.

10.4.13. Set the video priority settings

Description: This command sets the video priority order of the Autoselect mode.
Command {VIDEOPRIORITY=<vpmode>}
Response (VIDEOPRIORITY=<vpmode>)CrLf ← (VIDEOPRIORITY=4)CrLf
Legend:
Page 76 / 107
<code>: short name for type of log entry
<param>: technical parameter
<occ>: occurrence number for this type of log entry
Format
{ELEVELSEND#<p>=
<0>,<1>,<2>,<3>,<4>}
<0>,<1>,<2>,<3>,<4>)CrLf
<0>: 'Notice' level events
<1>: 'Warning' level events
<2>: 'Matter' level events
<3>: 'Error' level events
<4>: 'Fatal' level events
Format
<0>,<1>,<2>,<3>,<4>)CrLf
Please read section
Format
<vpmode> Three kinds of video priority modes can be:
<0>
→ {ELEVELSEND#1=0,0,1,1,1}
← (ELEVELSEND#1=0,0,1,1,1)CrLf
must be 1 = RS-232
0 = no immediate message send
1 = immediate message
0 = no immediate message send
1 = immediate message
0 = no immediate message send
1 = immediate message
0 = no immediate message send
1 = immediate message
0 = no immediate message send
1 = immediate message
→ {ELEVELSEND#1=?}
← (ELEVELSEND#1=0,0,1,1,1)CrLf
10.4.11 on page 76.
→ {videopriority=4}
First detect (factory default)
First the device check the DVI-D than VGA than the
HDMI video input port. That port will be selected
which contains valid video signal.
Section 10. Programmers reference
Example
Example
Example
