6. Operation of UMX-OPT-TX150R

6.1. Front and rear panel LEDs

VIDEO Status LEDs (DVI-D, DVI-A, VGA, HDMI) is
▪
ON when the video input port is selected and there is a valid video signal on it.
▪
BLINKING when the video input port is selected and there is no valid video signal on it.
▪
OFF when the video input port is NOT selected. Another port is active or there was a
disconnect command.
AUDIO Status LED (DVI-D, Audio 1, Audio 2, HDMI, S/PDIF) is
▪
ON when the audio input port is selected.
▪
OFF when the audio input port is NOT selected. Another port is active or there was a
disconnect command.
HDCP LED is
▪
ON when the incoming video signal is HDCP protected.
▪
OFF when the incoming video signal is NOT protected.
Autoselect LED is
▪
ON when the autoselect mode is selected and a valid video signal is found.
▪
BLINKING when the autoselect mode is selected and video signal searching is in progress.
▪
OFF when another video input port (DVI-D, DVI-A, VGA, HDMI) is selected.
LINK LED is
▪
ON when the TX and the RX (or OPT-IB) are connected to each other via the optical cable
and they can communicate.
▪
OFF when the TX and RX (or OPT-IB) are not connected or they CANNOT communicate.
RS-232 LED is
▪
ON when the RS-232 working mode is CONTROL.
▪
OFF when the RS-232 working mode is PASS.
KVM LED is
▪
always OFF in this firmware version. USB HID (KVM) extension is under development, only
available later.
EDID LED
▪
is ON when there is a valid EDID on the currently active input port.
▪
is BLINKING FAST continuously when there is an INVALID EDID on the currently active
input port.
▪
BLINKS FAST THREE TIMES when EDID learning was unsuccessful.
▪
BLINKS SLOW THREE TIMES when EDID learning was successful.
PWR LED is
▪
ON: when the transmitter unit is powered with +5V DC and ready to use.
▪
BLINKING: when the transmitter unit is powered but an error occurred.
▪
OFF: when the transmitter unit is NOT powered or out of order.
