SCANS

I Programmed scan operation

Scans specified frequency range, programmed in the
memory channel 1A/1b, 2A/2b and 3A/3b. Before start-
ing the programmed scan, scan edges should be pro-
grammed in these channels.
◊ Selecting scanning range
q Push [M/S•BAND] or [SUB] to select the desired
frequency band to be scanned.
w Push [SET] then [SCAN .] to enter the scan set
mode.
e Push [DN M] or [L UP] to select the programmed
scan item.
• "P-SCAn" is displayed.
r Rotate the tuning dial to select the desired scanning
range from 1A-1b, 2A-2b and 3A-3b.
• Push [M-CL 5] for 1 sec. to return to the default setting.
t Push [SCAN .] to exit from the scan set mode.

I Memory scan operation

Scans programmed memory channels only. Blank
channels and programmed scan edge channels
(1A/1b, 2A/2b and 3A/3b) are not scanned.
q Push [M/S•BAND] or [SUB] to select the desired
frequency band to be scanned.
w Push [V/M 1] to select memory mode.
e Push [SCAN .] to start the memory scan.
• "SCAN" indicator flashes.
• Pushing [SPCH•LOCK] for 1 sec. during scan starts
mode select scan and "LOCK" indicator appears. (p. 47)
r Push [SCAN .] to cancel the scan.
46
wSelect qSelect VFO
mode. mode.
eStart.
rStop.
From The N3UJJ.COM Document Library From The N3UJJ.COM Document Library
◊ Starting the programmed scan
q Push [M/S•BAND] or [SUB] to select the desired
frequency band to be scanned.
w Push [V/M 1] to select VFO mode.
e Select the desired operating mode.
• The operating mode can also be changed while scan-
ning.
r Push [SCAN .] to start the programmed scan.
• "SCAN" indicator flashes.
• The tuning step setting is used for the scanning step.
• 1 kHz or 1 MHz tuning step can also be used as the
scanning step.
t Push [SCAN .] to cancel the scan.
If the same frequency is programmed into the scan
edge memory channel 1A and 1b, 2A and 2b or 3A
and 3b, programmed scan does not start.
FM
S 1 3 5 7 9 20
FM USB LSB CW N
T- SQL ATT P.AMP AFCNB F
S 1 3 5 7 9 20
VFO A
40 60dB
SCAN
Flashes while scanning
qSelect memory
mode.
wStart.
eStop.
MEMO
AGC
60dB
40
SCAN
Flashes while scanning
