◊ SUB tuning dial assignment
q Push [SET] then [RIT] to enter the RIT/SHIFT set
mode.
w Push [DN M] or [L UP] to select [RIT] or [SHIFT]
control to be assigned.
• "rit nob" or "SFt nob" appears.
e Rotate the tuning dial to select the condition as de-
scribed below.
• Pushing [M-CL 5] for 1 sec. selects the default setting.
r Push [SET] to exit from the RIT/SHIFT set mode.
The [RIT] control functions as [RIT]
even when the SUB tuning dial
function is in use. (default)
The [RIT] control can be used for
MAIN band tuning.
The [RIT] control can be used for
SUB band tuning.
The [RIT] control can be used for
SUB band IF shift control.

I Dial lock function

The dial lock function prevents accidental changes
caused by the tuning dial (including the SUB tuning dial
function).
➥ Push [SPCH•LOCK] for 1 sec. to turn the dial lock
function ON and OFF.
• "LOCK" indicator appears while the dial lock function is
activated.
[SPCH•LOCK] for 1 sec.
From The N3UJJ.COM Document Library From The N3UJJ.COM Document Library

BASIC OPERATION

[DN M] [L UP]
[SET]
The [SHIFT] control functions as
[SHIFT] even when the SUB tuning
dial function is in use. (default)
The [SHIFT] control can be used for
SUB band IF shift control.
The [SHIFT] control can be used for
MAIN band tuning.
The [SHIFT] control can be used for
SUB band tuning.
FM
S 1 3 5 7 9 20 40 60dB
FM
S 1 3 5 7 9 20 20 40 40
LOCK
LOCK indicatior
4
[RIT]
[SHIFT]
[RIT]
VFO A
VFO A VF
60dB 60dB
25
