8
SATELLITE OPERATION

I Preparation

q Decide on a usable satellite.
w Confirm the approximate location of the satellite and
operating mode (e.g. "B," "J," etc.) through docu-
mentation (magazine, etc.) or via appropriate satel-
lite tracking software.
e Set the antenna direction for the desired satellite.
r Select satellite mode on the transceiver.
• Push [SATELLITE].
• Push [F-INP ENT
ing mode if desired.
t Select operating mode.
Satellite
Reverse tracking type
Normal tracking type
Downlink (receive) frequency
USB USB
S 1 3 5 7 9
NOR
SATL
RE V
S 1 3 5
Satellite mode indication
y Set the downlink frequency (MAIN band) to the bea-
con frequency.
• Refer to a ham magazine or book for detailed informa-
tion.
• Adjust the antenna direction so that the S-meter shows
to its strongest level.
• The S-meter level should be noted for transmit power
adjustment during a loop test.
USB USB
S 1 3 5 7 9
SATL
RE V
S 1 3
50
NOR ↔ REV ] for 1 sec. to select track-
Downlink Uplink
(MAIN band) (SUB band)
USB (or CW) LSB (or CW)
USB (or CW) USB (or CW)
20 40 60dB
LSB
MEMO
7 9 20 20 40 40 60dB 60dB
Uplink (transmit) frequency
20 60dB
40
USB
MEMO
5 7 9 20 20 40 40 60dB 60dB
From The N3UJJ.COM Document Library From The N3UJJ.COM Document Library
u Perform a loop test.
• Set the downlink frequency (MAIN band) to a vacant fre-
quency within the satellite's coverage.
• Push [SWP 0 Í] then, set the uplink frequency (SUB
band) while transmitting a single tone such as a whistle
to find your downlink signal and monitor your own signal
correctly. Push [SWP 0 Í] after setting.
USB USB
S 1 3 5 7 9 20
LSB
SATL
RE V
S 1 3 5 7 9
NOTE: To avoid excessive power, set the output
power so that the downlink signal strength is lower
than the beacon's strength.
USB USB
S 1 3 5 7 9 20
LSB
SATL
RE V
S 1 3 5 7 9
i Set the desired frequency to begin your satellite
communications.
• Both the downlink and uplink frequencies are changed
simultaneously.
o When your downlink audio drifts (Doppler effect),
push [SWP 0 Í] then rotate the tuning dial to ad-
just the uplink frequency (SUB band) only.
Push [SWP 0 Í] again after setting.
• When a particular station's audio is off frequency, use
the RIT function (push [RIT]).
!0 To exit the satellite operation, push [SATELLITE].
CONVENIENT: As the transceiver has 10 satellite
memory channels, once set, desired satellite fre-
quencies can be recalled instantly.
NOTE: As the downlink (MAIN band) signal is ap-
plied to the SUB band unit in-circuitry in satellite
mode, an optional FL-133
essary to operate CW-N mode.
40 60dB
MEMO
20 20 40 40 60dB 60dB
40 60dB
MEMO
20 20 40 40 60dB 60dB
is nec-
CW NARROW FILTER
