I General Set Mode - Icom IC-910H Instruction Manual

10
SET MODE

I General set mode

Display backlight brightness
Adjust backlight brightness for the function display to
the desired level within 0 (dark) to 100 (bright) range.
Beep tone
Adjust key touch beep output level to the desired level
within 0 (no output) to 100 (max. output) range.
RF/SQL control assignment
Assign [RF/SQL] control function from rF/SqL, Auto
and SqL.
• rF/SqL : RF gain and squelch controls are combined
for SSB/CW mode. Acts as squelch control
for FM mode.
• Auto : Acts as either an RF gain or squelch control
depending on operating mode.
• SqL : Acts as squelch control for all modes. RF
gain is set to maximum level in this setting.
Peak hold function
Turn the S-meter peak hold function ON or OFF.
The peak level is indicated for approx. 0.5 sec. when
this function is activated.
56
