  • Page 1 PROGRAMMING GUIDE 5- one signaling...

  • Page 2: Table Of Contents

    5Tone RX Code CH Window ..........................19 5Tone RX Code Setting Window........................20 5Tone TX Code CH Window ..........................20 5Tone TX Code Setting Window ........................21 Format Window ..............................22 User Tone Window ............................22 © June 2011 Icom America...

  • Page 3: Five-Tone Programming

    The following instructions assume that frequencies, tones, and squelch are set and the radios are in PMR mode (found in the Menu bar under Model). Additionally, the Auto Reset Timer must be enabled (Memory CH) and a value entered (Common -> Common). These instructions apply to all Icom radios with PMR capability. TX Radio:...
  • Page 4 Set to 1. Points to 1 line in the RX Code CH window: the RX Radio’s ID. RX Code CH (under 5 Tone) Field Setting / Description Line 1 » RX Code This particular radio’s RX ID. © June 2011 Icom America...

  • Page 5: Programming For 5-Tone Calls With Open Mic

    The following instructions assume that frequencies, tones, and squelch are set and the radios are in PMR mode (found in the Menu bar under Model). These instructions apply to all Icom radios with PMR capability. TX Radio:...
  • Page 6 Set to ON to enable open mic (setting not available on F3021 series radios) Common (under Common) Field Setting / Description Auto TX Timer Sets how long the mic stays open. Default is 60 seconds. (setting not available on F3021 series radios) © June 2011 Icom America...

  • Page 7: Programming For 5-Tone Calls With Ptt Id (Muted System)

    The following instructions assume that frequencies, tones, and squelch are set and the radios are in PMR mode (found in the Menu bar under Model). Additionally, the Auto Reset Timer must be enabled (Memory CH) and a value entered (Common -> Common). These instructions apply to all Icom radios with PMR capability. TX Radio:...
  • Page 8 Enter the digits you want displayed. For example: Send 98765, but if you only want 765 to show on this radios display, enter “345”. Now the last 3 digits of any 5 tone ID will be displayed. © June 2011 Icom America...

  • Page 9: Programming 5-Tone Non-Selective Transmissions With Ptt Id (Unmuted System)

    The following instructions assume that frequencies, tones, and squelch are set and the radios are in PMR mode (found in the Menu bar under Model). Additionally, the Auto Reset Timer must be enabled (Memory CH) and a value entered (Common -> Common). These instructions apply to all Icom radios with PMR capability. TX Radio:...
  • Page 10 Enter the digits you want displayed. For example: Send 98769, but if you only want 9876 to show on this radio’s display, enter 1234. Now the first 4 digits of any 5 tone ID will be displayed. © June 2011 Icom America...

  • Page 11: Programming For 5-Tone Emergency With Id

    The following instructions assume that frequencies, tones, and squelch are set and the radios are in PMR mode (found in the Menu bar under Model). Additionally, the Auto Reset Timer must be enabled (Memory CH) and a value entered (Common -> Common). These instructions apply to all Icom radios with PMR capability. TX Radio...
  • Page 12 Enter the digits you want displayed. For example: Send 98765, but if you only want 765 to show on this radios display, enter “345”. Now the last 3 digits of any 5 tone ID will be displayed. © June 2011 Icom America...

  • Page 13: Programming Kill/Stun/Revive In 5-Tone

    The following instructions assume that frequencies, tones, and squelch are set and the radios are in PMR mode (found in the Menu bar under Model). Additionally, the Auto Reset Timer must be enabled (Memory CH) and a value entered (Common -> Common). These instructions apply to all Icom radios with PMR capability. TX radio...
  • Page 14 Line 1 » RX Code RX radio Kill or Stun ID (from Memory Ch window) Line 1 » Text Add text, such as “Killed” Line 1 » Stun Select Kill or Stun from this menu © June 2011 Icom America...

  • Page 15: Programming Ptt Id With Dtmf Tone Id In 5-Tone

    The following instructions assume that frequencies, tones, and squelch are set and the radios are in PMR mode (found in the Menu bar under Model). Additionally, the Auto Reset Timer must be enabled (Memory CH) and a value entered (Common -> Common). These instructions apply to all Icom radios with PMR capability. TX radio...
  • Page 16 Sets which digits you want displayed on the RX radio display. For example: In receiving ID 23787, if you want the display too show the “378” part of the ID, enter in 234 (these are the digit spaces you want displayed) © June 2011 Icom America...

  • Page 17: Programming Select Call With Dtmf In 5-Tone

    The following instructions assume that frequencies, tones, and squelch are set and the radios are in PMR mode (found in the Menu bar under Model). Additionally, the Auto Reset Timer must be enabled (Memory CH) and a value entered (Common -> Common). These instructions apply to all Icom radios with PMR capability. TX Radio:...
  • Page 18 Set to 1. Points to 1 line in the RX Code CH window: the RX Radio’s ID. RX Code CH (under 5 Tone) Field Setting / Description Line 1 » RX Code RX radio ID (from Memory Ch window). © June 2011 Icom America...

  • Page 19: Programming Short Messages In 5-Tone

    The following instructions assume that frequencies, tones, and squelch are set and the radios are in PMR mode (found in the Menu bar under Model). Additionally, the Auto Reset Timer must be enabled (Memory CH) and a value entered (Common -> Common). These instructions apply to all Icom radios with PMR capability. TX Radio:...
  • Page 20 Line 1 » RX Code RX radio ID (from Memory Ch window). Line 2, 3… Enter any additional target radio 5-tone IDs in the RX Code field for all other messages. Under Text, enter each intended message. © June 2011 Icom America...

  • Page 21: Five-Tone Program Settings

    Sets the mute condition when a matching RX Code is received. Stun This setting will stun or kill a radio when the matching RX Code is received. Starts or cancels Scan upon reception of matching RX code. Scan © June 2011 Icom America...

  • Page 22: 5Tone Rx Code Setting Window

    When this field is set to ON, the radio releases the 5 tone mute after an answer back code is received. Determines if the TX Code is selectable from the front panel by the radio user. © June 2011 Icom America...

  • Page 23: 5Tone Tx Code Setting Window

    The decoder accepts this code regardless of the code programmed into the radio. Used when the same codes are repeated. (e.g. 11111 -> Repeat 1E1E1) Link2 Emits this code instead of no modulation between the station and ID codes. © June 2011 Icom America...

  • Page 24: Format Window

    Sets the low end of the decodable frequency range for the Decode Low (Hz) frequency defined in the Encode field. Decode High (Hz) Set the high end of the decodable frequency range for the frequency defined in the Encode field. © June 2011 Icom America...
  • Page 25 ©2008 Icom America Inc. The Icom logo is a registered trademark of Icom Inc. All other trademarks are the property trademark of Icom Inc. All other trademarks are the property trademark of Icom Inc. All other trademarks are the property 2380 116th Ave NE, Bellevue WA, 98004 of their respective owners.
