I Setting the satellite VFO

q Push [SATELLITE] to enter the satellite mode.
• "SATL" indicator with either "NOR" or "REV" indicator ap-
pears.
w Push [V/M 1] to toggle satellite VFO and memory
mode.
• VFO or memory mode indicator is displayed in the SUB
band (lower area).
e Push [SCAN . Â] to enable the downlink frequency
tuning.
• Uplink frequency indication disappears.
• Rotate the tuning dial to set the downlink frequency and
push [SSB/CW] to select the operating mode.
• Push [SCAN . Â] again after the tuning.
USB USB
S 1 3 5 7 9 20
LSB
SATL
RE V
S 1 3 5 7 9

I Tracking selection

NOR ↔ REV
• Push [F-INP ENT
tween normal and reverse tracking.
◊ Normal tracking
Both downlink and uplink frequencies increase or de-
crease in the same step simultaneously by tuning dial
rotation.
40 60dB
MEMO
20 20 40 40 60dB 60dB
] for 1 sec. to switch be-
[F-INP ENT]
[SATELLITE]
From The N3UJJ.COM Document Library From The N3UJJ.COM Document Library
SATELLITE OPERATION
r Push [SWP 0 Í] to enable the uplink frequency
tuning.
• Downlink frequency indication disappears.
• Push [SWP 0 Í] again after the tuning.
USB USB
S 1 3 5 7 9 20
LSB
SATL
RE V
S 1 3 5 7 9
NOTE: To select the operating mode for the uplink,
push [SUB] to enable the SUB band access.
◊ Reverse tracking
The downlink frequency follows the tuning dial rotation,
however, the uplink frequency changes in the reverse
direction to the tuning dial rotation in the same step.
USB USB
S 1 3 5 7 9 20 40
LSB
NOR
SATL
RE V
S 1 3 5 7 9 20 20
Satellite mode indication
8
40 60dB
MEMO
20 20 40 40 60dB 60dB
60dB
MEMO
40 40 60dB 60dB
Varies simultaneously
