4
BASIC OPERATION

I Operating band selection

The IC-910H can be used on the additional 1200 MHz
band with the optional UX-910. The operating band
can be selected by pushing [M/S•BAND] for 1 sec.
◊ Selecting on the MAIN band
q Push [SUB] to cancel the SUB band access, if re-
quired.
w Push [M/S•BAND] for 1 sec. to select operating
band.
NOTE: The same operating band cannot be as-
signed on both MAIN and SUB bands, simultane-
ously.
◊ Selecting on the SUB band
q Push [SUB] to enable the SUB band access.
• "SUB" indicator appears.
w Push [M/S•BAND] for 1 sec. to select operating
band.
20
(optional UX-910 is required)
From The N3UJJ.COM Document Library From The N3UJJ.COM Document Library
[SUB] [M/S•BAND]
Select 1200 MHz to MAIN band.
FM
S 1 3 5 7 9 20 60dB
40
S 1 3 5 7 9 20 20 40 40
Select 1200 MHz to SUB band.
FM
S 1 3 5 7 9 20 40 60dB
SUB FM
S 1 3 5 7 9 20 20 40 40
VFO A
VFO A VF
60dB 60dB
VFO A
VFO A VF
60dB 60dB
