Saving a preset

Save the current configuration (configuration 0) as a preset as follows:
1. Click the Save Preset button.
2. Select the desired preset by clicking on one of the presets listed. To create a
new preset, click one of the [unassigned] buttons. Overwrite an existing
preset by clicking that preset's button.
3. If desired, rename the preset by typing over the current name in the box
adjacent to the Save Preset button.
N Preset names are limited to up to 12 upper and lower case alphanumeric
N The following characters are invalid in preset names:
If you do not rename an unassigned button, the FOX 4G Matrix 14400
switcher names the preset as Preset {the selected preset number}, "Preset 08",
for example.
If you do not rename an existing preset when it is overwritten, the
FOX 4G Matrix 14400 switcher retains the same name.
4. Click the Accept button.

Recalling a preset

To recall a global preset to be the current configuration, click the button associated
with the desired preset.

Special Characters

The HTML language reserves certain characters for specific functions. The switcher
does not accept these characters as part of preset names, the switcher's name,
passwords, or locally created file names.
The switcher rejects the following characters:
{space} + ~ , @ = ' [ ] { } < > ' " ; (semicolon) : (colon) | \ and ?.
characters, {space}, _, and / characters.
+ ~ , @ = ' [ ] { } < > ' " ; : | \ and ?.
FOX 4G Matrix 14400 Switcher • HTML Operation 5-15
