3. If you selected IP [LAN] in step 2, the IP Connection window appears
(figure 4-4).
Figure 4-4 — Address and password entry
a. Examine the Matrix IP Address field in the IP Connection window.
The field displays the last Extron IP address entered.
If the IP address is correct, proceed to step 3b.
If the address is not correct, either click in the Extron IP Address field
and enter the IP address or click the scroll down button ( ) and select
from among the recently used addresses. Proceed to step 3b.
N If the local system administrators have not changed the value, the factory-
specified default, 192.168.254.254, is the correct value for this field.
If the switcher is password protected, click in the Password field and
b.
enter the appropriate administrator or user password.
Click Connect.
c.
• If you logged on using the administrator password or if no password
was required, the program connects you to the matrix switcher with
all of the administrator rights and privileges. The Extron Matrix
Switchers Control Program window (figure 4-5 and figure 4-6)
appears, displaying the current configuration of the attached matrix.
Proceed to step 4.
• If you logged on using the user password, the program connects you
to the matrix switcher with only user capabilities.
• If an incorrect password was entered, the program beeps and returns
to the password entry display.
FOX 4G Matrix 14400 Switcher • Matrix Software 4-5
