Figure 12. 4 x 3.5-inch Hard Drive Backplane Components (Rear View)

8 x 2.5" Hard Drive Backplane

Figure 13. 8 x 2.5-inch Hard Drive Backplane Components (Front View)

Figure 14. 8 x 2.5-inch Hard Drive Backplane Components (Rear View)

®
Intel Server System R2000LH2/LT2 Service Guide
A Power Connector
B SGPIO Connector
2
C I C Connector
D SATA Connectors
A SAS/SATA Hot-swap Connectors
A Power Connectors
B Mini-SAS Connectors
2
C I C Connector
Server System Features
11
