Customizing the SMX Window

In the SMX
program view by assigning device icons that represent the connected devices to each input
and output box.
1.
Click on an input or an output box. The Input Devices or Output Devices window opens,
containing icons representing various types of devices that may be connected to the
SMX.
2.
Click and drag an icon from the devices screen to an input or output box on the
program window. Repeat for additional devices, as desired.
3. In the
This caption appears in the descriptive window that pops up when you pass the cursor
over an input or output box containing an icon.
window, the inputs and outputs are represented by boxes. Customize the control
field, enter a caption (for example,
Caption
SMX System MultiMatrix Switcher • SMX Control Software
) for the device, if desired.
Laptop
75
