Revision code
07 July 2002
08 September 2002
09 June 2003
1362
Date
Manual revised to add CJ1M CPU Units and the new instructions that they support
(including support for binary refreshing for timer/counter PV). (Extensive changes too
numerous to list.)
New timer and counter instructions added: TIMX, TIMHX, TMHHX, TTIMX, TIMLX,
MTIMX, CNTX, CNTRX, and CNRX.
BCMP2 added.
"PC" changed globally to "PLC" when the meaning is Programmable Controller.
Page x: Manual added and product versions updated.
Pages 379 and 389: Example programming changed.
Page 489: Less than symbol changed to less than or equals symbol.
Page 490: Graphic changed.
Page 628: Operand changed in example and note added to example.
Pages 648 and 651: First entry for error flag changed.
Page 666: Bit numbers corrected in table.
Page 701: Graphic for R+1 changed.
Pages 728 to 748: Instructions reworked.
Pages 787, 814, 816 to 832: Information added on automatic port allocation.
Pages 820 and 825: Precautions added.
Page 833: Precautions on using Memory Cards added.
Page 873: Bottom half of page modified.
Manual revised to add CS1D CPU Units.
The following changes were also made.
Page xiii: Caution added.
Pages xiv to xviii: Application Precautions replaced with same section from Program-
ming Manual.
Page 4: Description of the operation of immediate refreshing changed.
Page 9: Data types added.
Pages 222 and 225: "Do not use" added to graphic.
Page 683: Ramp response graphic corrected.
Pages 10 and 11: Note with examples added on instructions executable when input con-
ditions are OFF.
Page 24: Table updated and note added for instructions not supported by CS1D CPU
Units and CS1 CPU Units with -V1 suffix.
Pages 26 to 28: Table updated and note added for instructions not supported by CS1D
CPU Units.
Pages 36 and 37: Table updated and note added for instructions not supported by CS1D
CPU Units.
Pages 144, 148, and 152: Tables updated and notes added for new CPU Unit models.
Page 233: Note added with information on adding counters using online editing.
Page 293: Information on condition of first destination word removed.
Page 679: Information added to graphic.
Pages 681 and 691: Terms added to table to clarify meaning of parameter settings.
Page 692: Bit numbers corrected (swapped) for output range and integral and derivative
unit.
Page 710: Information on outputting negative values in scaling results changed.
Page 781: Error Flag conditions added to table.
Page 791: Information added to note on executing PLS2(887).
Page 794: Corrections made to table.
Page 797: Information added to note on executing PLS2(887).
Page 824: Ladder programming corrected for process B.
Page 831: "I/O Unit's" corrected to "Special I/O Unit's."
Pages 844 and 845: Information on first send and read words/addresses changed.
Page 894: Reference manual changed.
Page 899: Information on data file structure from page 912 of previous manual moved to
this page.
Page : Information on data file structure from pages 912 to 913 of previous manual moved
to this page.
Page 1110: ASCII code table from page 916 added.
Revised content
